Rosemount-RF-8732MEIPM

Rosemount™ 8712EM/8732EM/8750W Modbus ~ ETHERNET/IP 모듈(D-9 ~ RS485 케이블 포함)

작업 공간에 추가

선정 제품 설명

부품 번호:RF-8732MEIPM

사양

호환성
유틸리티 용수 응용 분야용 Rosemount 8750W 전자 유량계
Rosemount 8732E 필드 마운트 전자 유량계 트랜스미터
Rosemount 8712E 전자 유량계 트랜스미터
Protection class
IP20
Dimensions
4.72” × 2.95” × 1.06”
L×W×H (120mm × 75mm × 27mm)
Power Supply
24 V ±10%
Power Consumption
Maximum: 280 mA on 24 V
Typical: 100 mA
Compatibility
Rosemount 8732E Field Mount
Transmitter with Rosemount 8705, 8711, and 8721 sensors; 8750W Utility Flow Meter System
Certifications
Fully ODVA Certified

특징

  • Pre-configured to deliver simple, fast EtherNet/IP system integration
  • Streamline operations with a convenient web interface for flow meter configuration, management and maintenance
  • Increase productivity and process insight with control system access
  • Cut costs with no input cards or high-speed counter cards required
  • Easily install and use with intuitive design and plug-and-play simplicity
  • Browser-based configuration and administration for access to full meter configuration settings
  • Enhance maintenance practices with diagnostic parameters, alerts and tools
